Horizontal Laminar Air Flow Cabinet
Product Details:
- Filter Type HEPA Filter
- Lighting 300 LUX - Fluorescent Illumination LED Light and UV Light
- Power Consumption 150 Watt (W)
- Frame Material Stainless Steel
- Filters 0.3 micron Minipleat Box Type H14 Grade HEPA Filter with Efficiency 99.999%
- Door Front Sash with Acrylic or Polycarbonate
- Nozzle SS 304, Atmospheric Nozzle
- Supply Ability : 50 Unit Per Week
- Click to view more
Price And Quantity
- 60000 INR/Unit
- 60000.00 - 125000.00 INR/Unit
- 1 Unit
Product Specifications
- 2 Feet X 2 Feet X 2 Feet Foot (ft)
- Class 100 / ISO 5 requirements as per ISO 14644 - 1:1999 (E)
- Stand Mounted
- Air Clean Bench
- 50 Kilograms (kg)
- Galvanized steel
- Pharmaceutical Industries, Hospitals and Medial, Microbiology Laboratories, Chemical Research Laboratories, Food Processing Industries, Electronics Industries
- SS 304, Atmospheric Nozzle
- Front Sash with Acrylic or Polycarbonate
- 220 to 240 Volt (v)
- 90 FPM ft/min (LFM)
- 0.3 micron Minipleat Box Type H14 Grade HEPA Filter with Efficiency 99.999%
- Stainless Steel
- HEPA Filter
- 300 LUX - Fluorescent Illumination LED Light and UV Light
- 150 Watt (W)
Trade Information
- Ahmedabad
- Cash on Delivery (COD), Cash Advance (CA), Letter of Credit (L/C), Western Union, Paypal, Letter of Credit at Sight (Sight L/C), Cash Against Delivery (CAD), Telegraphic Transfer (T/T), Delivery Point (DP), Days after Acceptance (DA), Cash in Advance (CID), Cheque
- 50 Unit Per Week
- 3 Days
- Yes
- Contact us for information regarding our sample policy
- Bubble Wrap - Free Wooden Packing - 3% of Basic Amount
- Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Central America, Asia, Africa
- All India
- CE Certificate for HEPA Filters, Blowers and Differential Pressure Gauge. and NABL Certificate for DP Gauge
Product Description
Key Features and Specifications:
- Horizontal Flow
- MOC as SS 304, SS 316 or SS 316L
- 90 FPM Velocity at 150 mm From HEPA Filter Face, (0.45 m/s)
- 0.3 micron Minipleat Box Type H14 Grade HEPA Filter with Efficiency 99.999%
- 10 micron Flange Type EU4 Grade HEPA Filter with Efficiency 90%
- Analog Type Differential Pressure Gauge with Range: 0 to 25 mm of WC
- Motor Blower Single Inlet or Double Inlet Centrifugal Type
- Speed Variable to adjust the speed of Blower
- 300 LUX - Fluorescent Illumination LED Light
- ON / OFF Push Button with Audio Alram For Blower Tripping
- UV Light for Disinfection
- Power Supply 220-240V, 50 Hz, Single Phase
Construction
- Polycarbonate Side Panels
- Easy to Clean and to disinfect, Design according to GMP Guidelines and EN ISO 14644 Compliance
- No Sharp Edges
- Less than 65 dB Sound Level on scale
- Minimum Vibration Level
- Front Sash with Acrylic or Polycarbonate
- SS 304 DOP/PAO Test Port (For HEPA Filter Testing) and Atmospheric Nozzle
Documentation
- Design Qualification
- Installation Qualification
- Operational Qualification
Certificates
- Calibration Certificate for Differential Pressure Gauge
- Test Certificate for Motor Blower
- Test Certificate for HEPA Filter and Pre Filter
- Test Certificate for Controller
- M.O.C. Certificate (Material of Construction)
- Other Required Certificates and Drawings
Optional Features & Accessories
- Flame Proof Design & Construction
- SS 304 Gas Coke
- Switch Socket 5-15 A
- UV Hour Meter (External)
- Digital Differential Pressure Gauge with Alarm Hour Meter
- Extra UV Light and Fluorescent LED Light
- Digital 2 Line Feather Touch Display
- Castor Wheels at Bottom
- Arm Rest and Leg Rest
Performance Validation at Site
- Velocity Measurement
- HEPA Filter Leak Test
- Particle Counting
- Air Flow Pattern Test
- Recovery Test
Areas of Application
- Pharmaceutical Industries
- Hospitals and Medial
- Microbiology Laboratories
- Chemical Research Laboratories
- Food Processing Industries
- Electronics Industries
Product Details
Brand | Airomax |
Type | Horizontal |
Material | MS (GI) Powder Coated with SS 304 |
Air Flow | Unidirectional Class 100 / ISO 5 Horizontal Flow |
Surface Finish | Matte Finish No. 4 |
Model Name/Number | HLAF-3X2X2 |
Power Supply | 220-240 Volts,50 Hz,Single Phase |
Noise Level | Less than 65 Db on scale |
MOC | MS (GI) Powder Coated with SS 304,1mm with 40 X 40 Square pipe structure |
Velocity | 6" From HEPA Grill,0.45 +- 0.05 mps (90 +- 20 FPM) |
Working Area | 3 Feet (Width) X 2 Feet (Depth) X 2 Feet (Height) |
Air Cleanliness | Class 100 requirements as per ISO-14644 |
Pressure Gauge | Magnehelic Gauge,1 No.,0-25 WC |
Vibration Level | Minimum |
Pre Filter | G4 grade with efficiency of 90-95% at 10 Micron |
Fan Motor | Centrifugal Type / Backward Curved Type |
Country of Origin | Made in India |
Work Table | 1 mm,SS 304,Matte Finish |
Front Sash | Polycarbonate |
Side Panel | 6 mm PC X 2 Nos. |
HEPA Filter | H14 Grade efficiency 99.997% at 0.3 Micron |
DOP/PAO Test Port | 1 No.,SS 304 |
Magnehelic Pressure Port | 1 No.,SS 304 |
Gas Cock | 1 No.,SS 304 |
Castor Wheels | 4 Nos. |
Control | ON/OFF Switches for Blower,LED/UV Control |
Fluorescent LED Light | 2 Feet X 1 No. |
UV Light | 1.5 Feet X 1 No. |
Auxiliary Power Socket | 5-15 A,1 No. |
Alarm System | Audio Alarm / Blower Trip |
Documentation | DQ,IQ,OQ along with complete set of Certificates |
