Product Showcase
Hospital Pass Box Hospital Pass Box Hospital Pass Box Hospital Pass Box Hospital Pass Box Hospital Pass Box
Hospital Pass Box
Hospital Pass Box Hospital Pass Box Hospital Pass Box Hospital Pass Box Hospital Pass Box

Hospital Pass Box

Product Details:

  • Dimension(L*W*H) 300 mm X 300 mm X 300 mm Millimeter (mm)
  • Frame Material Stainless Steel
  • Feature Electromagnetic Door Interlocking System
  • Lighting 300 LUX - Fluorescent Illumination LED Light
  • Type Pass Box
  • Floor Floor Mounted / Wall Mounted
  • Application Pharmaceutical Industries, Hospitals and Medial, Microbiology Laboratories, Chemical Research Laboratories, Food Processing Industries, Electronics Industries
  • Supply Ability : 3 Per Day
  • Click to view more
X

Price And Quantity

Product Specifications

  • Stainless steel
  • Pharmaceutical Industries, Hospitals and Medial, Microbiology Laboratories, Chemical Research Laboratories, Food Processing Industries, Electronics Industries
  • Stainless Steel Sandwich Type Door with View Panel
  • Floor Mounted / Wall Mounted
  • Electromagnetic Door Interlocking System
  • 300 LUX - Fluorescent Illumination LED Light
  • Pass Box
  • 300 mm X 300 mm X 300 mm Millimeter (mm)
  • Stainless Steel

Trade Information

  • Cash Advance (CA)
  • 3 Per Day
  • 3 Days
  • Yes
  • Within a certain price range free samples are available
  • Free - Bubble Wrap
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • All India

Product Description

Static Pass box is used to transfer the materials from one side to other side through a controlled environment in order to avoid cross contamination of airborne particles. It is fixed between two cleanroom areas having same grade/class of air. It prevents the entrance of contaminants in the sterile area. Door Interlocking is the primary feature of a pass box, when one side door is open the other side door remains closed. It is also known as Cleanroom Pass Through box, Hospital Pass box, Passive Pass Box, Hatch Box and Transfer Hatch etc.

Key Features and Specifications

  • Design according to GMP Guidelines
  • Easy to Clean and to disinfect
  • EN ISO 14644 Compliance
  • Electromagnetic Door Interlocking System
  • No Sharp Edges
  • Pencil Coving for Internal Working Area
  • Sturdy Built Doubled Skin Body
  • Advanced airtightness
  • Easy Integration
  • Less than 65 dB Sound Level on scale
  • Minimum Vibration Level
  • MOC as SS 304, SS 316 or SS 316L
  • Feather Touch Display Each Side
  • Fluorescent Illumination LED Light
  • UV Light for Disinfection
  • Process Lock Timer (Inbuilt)
  • Door Open/Close Delay Alarm (Inbuilt)
  • UV Hour Meter (Inbuilt)
  • SS 304 Door Hinges and Door Handles
  • 30 MM Double Skin Doors with View Panel
  • 5 MM Toughened Glass as View Panel
  • Power Supply 220-240V, 50 Hz, Single Phase

 Mounting

  • Wall Mounting
  • Stand Mounting
  • Floor Mounting

 Documentation

  • Design Qualification
  • Installation Qualification
  • Operational Qualification

 Certificates

  • M.O.C. Certificate
  • Test Certificate for Controller
  • Other Required Certificates

 Optional Features & Accessories

  • Flame Proof Design & Construction
  • Three Way Static Pass Box
  • L Type Construction
  • Support Stand for Pass Box Mounting
  • UV Hour Meter (External)
  • Digital Differential Pressure Gauge with Alarm Hour Meter
  • Extra UV Light and Fluorescent LED Light

Areas of Application

  • Pharmaceutical Industries
  • Hospitals and Medial
  • Microbiology Laboratories
  • Chemical Research Laboratories
  • Food Processing Industries
  • Electronics Industries
